Acid Stimulation

Acid Stimulation Additives

Although the main purpose of acidizing operations is to remove the skin on the formation, increase the permeability in order to improve the inflow performance; protecting the tubulars and preventing any damage to downhole tools should also be considered. CS OILFIELD provides the most suitable acid stimulation products based on formation, temperatures, nature and strength of acid and type of the steel used.

LIST OF PRODUCTS
Corrosion Inhibitor -1 (S – CI 140) Up to 15 – 28% HCl, Effective to 140 °C
Corrosion Inhibitor -2 (S – CI 200) Up to 15 – 28%, Works with salinity
Intensifier (S-IN 300) Able to work with corrosion inhibitors for HT
Iron Control -1 (S-IC 150) Can be used up to 400°F
Iron Control – 2 (S-IC) Compatible with production fluids
Non-emulsifier (S-NE X) Compatible with all production fluid types
Surface Tension Reducer (S-SURF RX) Compatible with other chemicals
Anti-sludge Agent (S-AS) Compatible with other chemicals
Acid Gelling Agent (S-GEL A) Can be used up to 150 °F
Clay Control (S-CAY HIB) Used between 10 to 193 °C.
S-CC 110 Compatible with all acid types

Self-Diverting Acid System

CS OILFIELD Self Diverting Acid System (CS – SDA) provides sufficient retardation and helps prevent excessive leak-off through wormholes of carbonates. CS- SDA is used in combination with other acids to improve zone coverage. It has proven one of the most effective diverting systems for carbonate matrix acidizing.

System functions by in-situ crosslink of the polymer. This occurs as the acid is spent, the pH of the fluid increases causing the polymer to complex, when the fluid is completely spent, the fluid system breaks back. CS-SDA contains no solids or particulates which could bridge when pumping, can be used in either cased hole or open hole completions since it diverts in the formation rather than on it. CS-SDA has the greatest potential in treating zones with widely varying permeability streaks and horizontal wells.

CS - SD020

Diverter Gelling Agent

CS - SD021

Metal Crosslinker

CS - SD022

Stabilizer

CS - SD023

Breaker
